CMT Terminal Azeri Oil

Basic Port Info

CMT-BTC AZERI OIL BASIC PORT INFORMATION

========================================

PORT FACILITIES SECURITY

========================

- Security level of port       : 1

- Name/Contact details of PFSO : Mr. ABDULKADIR UYSAL

                            Tel: +90 (322) 355-1700

NUMBER OF TUGS : as per port regulations tugs are used on basis of GT as under:

GT TUGS

-------------- --------

2000 - 5000     1

5001 - 30000    2

30001 - 75000   3

75001 and up    4

The general particulars of the terminal are as follows:

                                      Berth No.1 E    Berth No.2 W

--------------------                  ------------    ------------

- Min SDWT Metric Tons                   80,000         80,000

- Max Sdwt Metric Tons                  320,000        320,000

- Max Displacement

  While Mooring M/T                       150,000      150,000

- Min/Max Loa (in meters)                 235/350      235/350

- Max Draft (in meters)                      24.0         24.0

- Water depth (in meters)                    27.0         28.0

- Max Height of Manifolds (Mtrs)             25.0         25.0

- Manifold Height from

  Sea Level Minimum                          5.70         5.70

  Maximum                                   25.00        25.00

- Min freeboard Not applicable Not applicable

- Min/Max beam (in meters)                  43/60     43/60 (42,0 m acceptable)

- Number X Size of manifolds

. Cargo lines                              3 X 16"      3 X 16"

. Vapor Return Line                        1 X 16"      1 X 16"

(VOC: Volatile Organic Compound

is located on the South end of

the Loading Arms)

- Loading Rate

(CBM per hour per

manifold/Loading arm)                       4,000         4,000

- Presentation flange is 16 ASA 150.

- Minimum Ballast Parallel Body length of 42.5 m either side of the manifold

Total from 3 loading arms = 9,500 CBM/H

Vessel is in compliance with the latest requirements of OCIMF Recommendations for Mooring Equipment Guidelines.

------------------------------------------------------

Vessel is in compliance with the latest requirements of OCIMF Recommendations for Tanker Manifolds and Associated Equipment.

------------------------------------------------------

Vessel has to be equipped with a Vapour Emission Control System (VECS) which is certified by an International Classification Society and is fully operational.

------------------------------------------------------

Vessels Inert Gas system is fully operational and all cargo tank atmospheres are 6% or less oxygen content by volume.

------------------------------------------------------

Vessels cargo tanks do not contain concentrations of H2S or Mercaptans in excess of the Threshold Limit Value, (TLV). Concentrations within each individual cargo tank are to be advised. TLV limits defined as per American Conference of Governmental Industrial Hygienists, Inc (ACGIH).

------------------------------------------------------

Crane/derrick at manifold is certified and has minimum 15 tonnes SWL capacity

Pls note the following Basic Information :

1. LMT = GMT + 2 Hours

2. Terminal Located At : 36 51.0 N - 035 56.0 E

3. Anchorage Area : Outside of 1 Mile-Radius-Area From end of Jetty.

4. Pilotage and tugging are compulsory.

5. Prearrival

Pre-arrival Information

=======================

Prior to arrival at the Terminal, the Master shall advise the Company of:

1. ETA, last cargo, last port and destination.

2. The time of Notice of Readiness

3. Working pressure of Vapour Return Line onshore is 20 milibars (200 mm Wg).

Maximum working pressure is 80 milibars. Usage of vapour return line is

compulsory. The tanker must berth with all her tank pressures below 20

milibars. Please acknowledge receipt of this information.

4. Confirm vessel carries on board a valid Oil Pollution Certificate.

5. Confirm vessel carries on board all appropriate charts and that these are up

to date.

6. Confirm that appropriate passage plan has been prepared for voyage.

7. Confirm aft leading accommodation ladder.

8. Confirm Inert Gas system is fully operational and all cargo tank atmospheres

are 6% or less oxygen content by volume.

9. Berthing displacement on arrival.

10. Confirm cargo tanks do not contain concentrations of H2S or Mercaptans in

excess of the Threshold Limit Value, (TLV), H2S 5 ppm, Mercaptans 0,5 ppm

and advise concentrations within each individual cargo tank,

(Ref. Paragraph 9.14).

11. Was the last cargo carried a high Sulphur or Mercaptans content crude?

12. Quantity (barrels) of crude to be loaded and required loading rate.

13. Confirm number, size and disposition of crude oil loading and vapour return

manifold connections.

14. Confirm vessel can perform closed operations.

15. Confirm vessel equipped with a fully operational and approved closed Vapour

Return System, Vapour Emission Control System, (VECS). System works on max:

80 mbar.

a. Set pressure (pressure/vacuum) on PV Breaker of Shore inert gas line.

b. If applicable, set pressure on pressure/vacuum valves on individual cargo

tanks.

16. Any impending Arrestment of the vessel or cargo of which the Master is or

becomes aware.

17. The arrival and sailing drafts.

18. What is the side rail / roll bar height from sea level on arrival?

19. The distance between centers of each cargo manifolds?

20. The number of cargo manifolds?

21. The distance between center of vapour manifold to center of closest cargo

manifolds.

Note : Masters strictly have to fulfill the requirements of items 3, 8 and 10 when they berthed to our terminal.

Violation of these requirements will cause unberthing of vessels and all expenses incurred will be on owners account.

Master to cable following Info

==============================

- Summer Dwt/Original Grt- NRT

- Arrival Draft/LOA/Registry nbr/IMO no.

- Last port / next port

- Master's name / number of crew

We kindly ask you to e-mail (iskenderun2007@boutros.com.tr) asap the following certificates:

==============================================================================

INTERNATIONAL SHIP SECURITY CERTIFICATE

CLC-92 or INSURANCE CERTIFICATE

SAFETY CONSTRUCTION CERTIFICATE

REGISTRY CERTIFICATE

INTERNATIONAL TONNAGE CERTIFICATE (1969)

CREW LIST

Meanwhile we kindly ask you to fill up and send back the attached forms:

=======================================================================

THE WASTE NOTIFICATION FORM

BALLAST WATER REPORTING FORM

REPORTING FORM

PORT OF CALL LIST FOR LAST TEN PORT

Thanks.

6. Berthing/Unberthing Carried out round the clock.

7. Mooring arrangement

The vessel is secured alongside with suitable ropes or wires which are to the

satisfaction of the Marine Operations Manager. A minimum of seven (7) mooring

lines must be used at each end of the vessel. The use of mooring lines of

dissimilar materials is not accepted. The use of wire springs, (with or

without synthetic fibre rope tails which shall not exceed 11 metres in length

overall and should have a breaking strain at least 25% greater than the

breaking load of the wire to which they are attached), is required.

Vessels must be able to deploy 3-2-2 mooring configuration using moorings of

similar material and nominal diameter both forward and aft, all moorings

should be fitted to mooring drums to faciliate appropriate load adjustment

throughout operations alongside.

For vessels fitted with wire rope moorings, these should be fitted with

synthetic tails and preferably deployed from a split drum arrangement.

Alternatively, low stretch synthetic ropes may be substituted for wire if the

elongation of the rope at 55% breaking load does not exceed 3% of the rope

length.

- Winches

Mooring ropes or wires shall only be fastened to the proper fixtures provided

for this purpose. Self-tensioning winches must not be used in automatic mode

and winch brakes must be kept hardened up except when moorings are being

tended.

- Wire Reeling

Mooring wires and lines shall be reefed on their drums in the direction which

enhances brake power, see diagram below.

8. No facilities for dirty ballast / slops.

9. Master to cable 72/48/24 hours notices

10. Vessel will berth alongside Jetty where Gangway and loading arms are

automatically given from shore. Berthing Side can only be known once

berthing is scheduled.

11. Master to contact ''Botas'' Terminal on Vhf Channel 16 or 22, for Pilotage.

12. Master to also contact on Vhf Botas Terminal immediately upon arrival

confirming time of arrival and time N.O.R. tendered.

13. Garbage fees are charged regardless whether the service is used or not.

Vessel to coordinate with the Pilot the disposal of garbage.

14. I M P O R T A N T

There is a ban on South Cyprus related vessels.

Vessels ;

- flying South Cyprus flag, or

- Registered at South Cyprus, or

- Owned or operated or managed by residents of South Cyprus, or

- Owned or operated or managed by South Cyprus citizens, even if they are

residents of other

countries, or

- vessels owned and/or managed by persons or their affiliates,

who have double nationality, one of which being South Cyprus,

- Regardless of their flag, vessels which have South Cypriot shareholders

are not accepted at Turkish ports.

Furthermore, regardless of its flag, any vessel which has cargo for

South Cyprus or coming from any South Cyprus port (loaded or on

ballast) or any vessel going from Turkey to any South Cypriot port

is not accepted at Turkish ports.

Vessels which are sold to other countries, if cannot submit the

proper documents proving the new register and that the old register

at South Cyprus has been canceled, are also not accepted.

15. Free Pratique is granted only upon boarding of the Sanitary Officer. To

avoid fines, Master to ensure that the yellow flag is hoisted until Sanitary

Officer grants the Free Pratique and gives approval to put the yellow flag

down.

16. Our office hours during which master can contact us on Vhf Channel 16 :

Everyday (Including Sat/Sun/Holidays during which we have one person on

duty) :

08:30 - 12:30 / 14:30 - 18:30 Lmt.

17. Telephone contact possible through Turk Radio Vhf Channel 16.

18. Fresh water is available alongside only. Cost is EURO 4.00 per Ton.

19. Bunkering or Lighterage not permitted while alongside.

20. Supply of provisions not permitted while alongside

21. Crew change permitted.

22. Please note Port State Controls commenced in Turkey.

23. Our Full Addresses :

BOUTROS AND FILS, ISKENDERUN

Ataturk Bulvari, Unsal Han - Kat 1

31200 Iskenderun - TURKEY

Phone : +90 (326) 613-4567 / +90 (326) 614-0230

Fax : +90 (326) 614-0234 / +90 (326) 614-0237

Telex : (0607) 68123 sail tr - (0607) 68131 sail tr

Phone   : +90 (326) 613-4567 / +90 (326) 614-0230

Fax     : +90 (326) 614-0234 / +90 (326) 614-0237

Telex   : (0607) 68123 sail tr - (0607) 68131 sail tr

E-mail  : iskenderun2007@boutros.com.tr

Web     : http://www.boutros.com.tr

Persons to Contact

------------------

Zekeriya Dik     +90 (532) 394-2802   zekeriya@boutros.com.tr  Ops Manager

Adnan Albayrak   +90 (532) 394-2801      adnan@boutros.com.tr

Murat Koroglu    +90 (539) 891-9223      murti@boutros.com.tr

Zeki Keser       +90 (537) 294-3306       zeki@boutros.com.tr

Axel E. BOUTROS +90 (532) 244-1234        axel@boutros.com.tr  Managing Owner

Emil E. BOUTROS +90 (532) 212-8888    emil2007@boutros.com.tr

24. Docs Required for clearance :

- Last port clearance

- Maritime health declaration

- 2 Copies of Port of Call List

- 8 Copies of Crew List

- 4 Copies of Store List

- 4 Copies of Crew Effect Declaration

Also a photocopies and Originals of the following certificates for the port authorities (Originals will be checked by the Harbor Master) :

- International Ship Security Certificate,

- Safety construction certificate,

- Safety equipment certificate & Form E,

- Safety radio certificate,

- International load line certificate,

- Classification certificate,

- Int. Oil pollution prevention Cert.,

- International Tonnage certificate (1969)(3 sets from all pages),

- Minimum safe manning (2 copies),

- Safety management certificate,

- Documents of Compliance,

- Certificate of registry,

- CLC certificate,

- Medical chest certificate,

- Ship Sanitation Control Exemption certificates,

- Continuous Synopsis Record,

- Sewage pollution prevention Cert.,

- Radio officerÍs certificate,

- GMDSS cert. copy of 3 officers,

(If no Radio/Officer on board)

- LICENCE OF COMPETENCE TO MERCHANT MARINE OFFICERS,

- ORIGINAL ENDORSMENTS OF THE OFFICERS (PHOTOCOPY/S NOT APPLICABLE)

(IF THE NATIONALITY OF THE OFFICERS IS OTHER THAN VESSEL'S FLAG)

Please do not hesitate to contact us for any further information you may require.
